Product parameters

Input voltage: ac100-240v50 / 60Hz

Input current: 0.6A (max)

Output voltage: 12VDC

Output current: 10-2000ma

Input surge current: 60A (max)

High voltage test: 3000vac10ma 3S

Ripple and noise: 120mvp Pmax

Energy efficiency: VI

Safety standard:

UL60950; UL60065; FCC Part 15 SubpartBClass B

IEC/EN60950;; EN55032; EN55022;

AS/NZS 60065:201

Safety index:

Insulation resistance: 50m Ω (at 500VDC)

Over current protection

Short circuit protection

Over voltage protection

Environmental requirements

Working temperature: - 5 ° C - + 40 ° C

Storage temperature: - 20 ° C - + 60 ° C

Working humidity: 30% - 85%

Storage humidity: 10% - 95%

authentication:

CB CE GS UL FCC CCC ULPSE KC BSMI VI

Security equipment, router, DVB, electronic dictionary, mobile phone, printer, monitor security, DVD, Robert wireless leilcopter, medical instrument, game machine, monitoring security system, router, DVB, robot and so on, it equipment, digital machine, projector scope of application: hard disk video recorder, monitoring power supply, water purifier, air purifier, Massage Pillow Massager, monitoring camera Charger of 3D printer beauty instrument
