Product parameters

AC input voltage: AC100-240V, 50 / 60Hz

Input current: 0.35A (maximum)

Output voltage: 5-5.5vdc

Output current: 100-2100ma

Input surge current: 60A (maximum)

High voltage test: 3000VAC 10mA 3S

Output voltage ripple and noise: 120mvp-pmax

Energy efficiency grade: VI

Safety standard:

UL60950;  FCCPart 15 Subpart B Class B;

IEC/EN60950; EN55032;  EN55022;

AS/NZS 60950-1:2015;

GB4943.1-2011; GB9254-2008; GB17625.1-2012

K60950;

Safety index:

Insulation resistance: 50m Ω (at 500VDC)

Over current protection

Short circuit protection

Over voltage protection

Environmental requirements

Working temperature: - 5 ° C - + 40 ° C

Storage temperature: - 20 ° C - + 60 ° C

Working humidity: 30% - 85%

Storage humidity: 10% - 95%

authentication:

CB CE GS ULFCC CCC PSE KC BSMI VI
