Features

AC input voltage:AC100-240V 50/60Hz

Input current:0.6A（max）

Output voltage:12VDC

Output current:100-2000mA

Input inrush current:60A(max)

Hi-pot test:3000Vac 10mA 3S

Output ripple &noise:150mVp-p max

Efficiency level:VI

Safety standard:

Safety Index:

Insulation resistors:50MΩ（at 500VDC）

Over current protection

Short circuit protection

Over voltage protection

Environmental Requirements

Operating temperature:-5°C-+40°C.

Storage temperature: -20°C-+60°C.

Operating humidity: 30%-85%.

Storage humidity: 10%-95%.

Certificate:

CB CE GS UL FCC CCC ULPSE KC BSMI VI

Outside drawing

Features

AC input voltage:AC100-240V 50/60Hz

Input current:0.6A（max）

Output voltage:12VDC

Output current:100-2000mA

Input inrush current:60A(max)

Hi-pot test:3000Vac 10mA 3S

Output ripple &noise:150mVp-p max

Efficiency level:VI

Safety standard:

Safety Index:

Insulation resistors:50MΩ（at 500VDC）

Over current protection

Short circuit protection

Over voltage protection

Environmental Requirements

Operating temperature:-5°C-+40°C.

Storage temperature: -20°C-+60°C.

Operating humidity: 30%-85%.

Storage humidity: 10%-95%.

Certificate:

CB CE GS UL FCC CCC ULPSE KC BSMI VI

Outside drawing

Security equipment, router, DVB, electronic dictionary, mobile phone, printer, monitor, DVD， ROBET Wireless leilcopter,  medical instrument, game machine, security monitoring system, Robot and so. IT series equipment, digital machine  and projector scope: Digital Video Recorder,monitoring power supply water purifier,air purifier massage pillow, massor,surveillance camera, 4D printer ,beauty instrument charger
